60l Akkumuléiere Blowdeld Maschinn

Model:KGB90A

Dës fix Ouverture an zoumaachen Dashdash Maschinn, mat duebelch Picken Rodchronomen an Uwendung vun der Unitienz. D'Produkter mat engem holldabléierervererve System fir séier Äntwert an Energie spueren opzeschalt. Tatsächlech Bouf Mokum Maschum-Mainstänn am Waasserfalthafte benotzt, aus méi wäit Boutddungen mat produzéieren.

Volume: 60LGewiicht: 14t

Schécken Ufro

Produkt beschreiwung Specification Application

De Standard KGB90A Modell, eng féierend Akkumulator Kappbladmaschinn Maschinn, enthält e Moog 100 Dicke Controller, Roboter Aarbechter, a Produktivitéit Dës 60L Zaloplruktioune, Spillsaache Maschinn ass IDen, autoriséierten Zoumaache, an de Verkéierbarkeetsbänner stackelt.

D'Features a Virdeeler

Dëse Modell ass eng fix Schimmel Ouverture an zouenen Typ, andeems Dir en Duebelbier SYNCHONOUS MELD MELDMISMISME, an den Uelegzylinder-Clamface
● Späicheren Zylinder stierwen Kapp Serie
● Maximum Volumen 60l
● pass op chemesch Verpackungsfarrel, grouss Spannungen, abs Auto-Schwäif, asw.
● Mat eenzegaarteger Technologie, modd Spannungsspräisystem, grouss Klamplerkraaft, schnell Schimmelbezuelungsgréisst

60L accumulate blow molding machine

Specifications

Serial number	Material PE、PP、ABS...	Fixed open- closing type Mold closing oil cylinder(single cylinder)
Serial number	Material PE、PP、ABS...	Machine model:KGB90A
Specifications
1	Max container capacity	60 L
2	Output(dry Cycle)	500 PC/HR
3	Machine Dimension(L×W×H)	5.45 M x 3.5 M x 4.2 M
4	Machine weight	14 T
Clamping Unit
1	Clamping force	280 KN
2	Mold platen size(W×H)	960 MM x 980 MM
3	Platen opening stroke	450 MM-1050 MM
4	Platen moving stroke	500 MM
5	Max mold size(W×H)	700 MM x 980 MM
6	Mold thickness	460 MM-550 MM
Power
1	Servo oil pump motor power	18.5 KW
2	Servopump displacement	150 L/MIN
3	Blow pressure	0.8 Mpa
4	Air consumption	1 M³/MIN
5	Cooling water pressure	0.3 Mpa
6	Water consumption	90 L/min
7	Average energy consumption	35 KW-45 KW
Extruder unit
1	Screw diameter	90 MM
2	Screw L/D ratio	24 L/D
3	Melting capacit for HDPE	130 Kg/hr-160 Kg/hr
4	Number of heating zone	4 ZONE
5	Screw heating power	17.6 KW
6	Screw fan power	0.5 KW
7	Extruder motor power	45 KW
Die head
1	Number of heating sections	5 ZONE
2	Heating power	26.8 KW
3	Max die-pin diameter	320 MM
4	Accumulator capacity	6.6 L
5	(PE)Accumulator weight	4.95 KG
